Pressure Gauge SS- 1/4" BSP- Rear -100/150kPa 63mm

Discover the exceptional reliability and accuracy of the SS- 1/4" BSP Rear Pressure Gauge, featuring a robust stainless steel 63mm case. Engineered for industrial applications, this pressure gauge operates effectively in environments where precision is crucial. With a measurement range of -100 to 150 kPa, this dual scale kPa gauge is ideal for hydraulic plants, mining, and irrigation equipment. Its sturdy construction includes a copper alloy bourdon tube and socket, ensuring durability under severe operational conditions. Designed for heavy-duty service, this gauge effectively withstands vibration and pulsation, which can wear down standard dry gauges over time. The plexiglass window and neoprene seal protect against corrosive ambient conditions, making it a perfect choice for harsh environments. With an accuracy rating of 1.6% and an operational temperature range of -25°C to +65°C, this pressure gauge meets the demands of various industrial settings. Whether you need a reliable gauge for your hydraulic system or require precise pressure readings in mining operations, the SS- 1/4" BSP Rear Pressure Gauge is your go-to instrument. Trust Smartfox AU for high-quality industrial gauges tailored to your specific needs.

63mm stainless steel case pressure gauges are robust industrial quality enclosed within a stainless steel grade 304 case and bezel. Plexi glass window and neoprene seal. Designed for heavy duty service where vibration or pulsation of medium would cause excessive wear on a dry gauge or where corrosive ambient conditions prevail.
Copper alloy bourdon and socket.
Specific application examples are hydraulic plant, mining and irrigation equipment.
Accuracy 1.6%
Ambient Temperature: -25 C to +65 C

TECHNICAL SPECIFICATIONS
Brand/ Model Gauges Pressure
Pressure Min & Max -100/150
Scale Type kPa- Dual
Glycerine Unfilled
Stem Mount Entry Rear
Connection 1/4" BSP
Mfr No. AT-D-4-2TM
